Over the years of exporting cable equipment, I’ve often been asked by customers: “I’m making 12-fiber cable now, but in a couple of years I want to make 24-fiber or higher – can the equipment be upgraded?”
This question seems simple, but behind it lies a core design philosophy in equipment manufacturing – modular design.
If an SZ stranding line wasn’t designed with expansion capability in mind, and the customer wants to upgrade from 12 tubes to 24 tubes, the entire machine might have to be scrapped. But with a modular-designed machine, you only need to add a pay-off stand module and upgrade the control system to achieve capacity expansion.
Today let’s talk about modular design in cable equipment, and why it directly affects the customer’s long-term return on investment.
1. What Is Modular Design? Why Does It Matter?
Modular design, simply put, means dividing equipment into several independent functional modules, each of which can be individually upgraded, replaced, or expanded.
Taking a fiber optic cable production line as an example, modular design is reflected at several levels:
Mechanical modularity: The pay-off stand, stranding unit, binder, and take-up of an SZ stranding line are each independent and can be added or replaced separately. The extruder, cooling trough, capstan, and take-up of a fiber optic cable sheathing line are likewise independent modules.
Electrical modularity: PLCs, inverters, sensors, and communication modules use standard interfaces and can be upgraded individually. The UV curing system of a fiber coloring machine can be replaced separately, and the temperature control module of a secondary coating line for optical fiber can be upgraded separately.
Control modularity: Software functions are divided by module – recipe storage, data acquisition, and MES integration can be enabled as needed. The loose tube line and the entire fiber optic cable making machine series are developed on a modular architecture.
Why does it matter? Because cable products are changing. Today you make 12-fiber loose-tube, tomorrow you might make 24-fiber high-count, and the day after you might make G.657 bend-insensitive cable. If the equipment can only make one product, the production line’s lifecycle is short.
2. How Does Modular Design Manifest in Actual Production?
Scenario 1: Expanding from 12 tubes to 24 tubes
A customer buys an SZ stranding line with a standard 12 pay-off positions. Two years later, the order mix changes and they need to make 24-fiber cable.
With a modular-designed machine, they only need to add a set of pay-off stand modules and upgrade the PLC program to achieve simultaneous stranding of 24 tubes. With a non-modular design, the entire machine might need to be replaced.
Scenario 2: From single product to multi-product changeover
A customer starts out making only loose-tube cable, then later takes an order for FTTH butterfly drop cable. A modular-designed fiber optic cable production line can add an FTTH optical cable manufacturing machine module, or adjust the dies and recipes of existing equipment, to achieve multi-product production.
Scenario 3: From manual operation to data-driven management
The customer’s factory implements an MES system and needs automatic equipment data upload. With modular-designed equipment, they only need to add a communication module and enable the data interface to achieve MES integration. With non-modular design, the PLC might not even support data output.
3. Hongkai’s Modular Design Approach
Hongkai considers modular architecture from the equipment design stage.
First, unified PLC platform. All equipment is developed on Siemens/Mitsubishi PLC platforms, supporting PROFINET and MODBUS TCP/IP protocols. Fiber coloring machine, secondary coating line for optical fiber, loose tube line, SZ stranding line, fiber optic cable sheathing line, FTTH optical cable manufacturing machine, indoor optical fiber production line – the entire series uses the same control platform, so data can be exchanged and speeds can be matched.
Second, standard interface design. Modules such as pay-off stands, stranding units, and take-ups use standard mechanical and electrical interfaces. If the customer later wants to increase pay-off capacity, change the take-up format, or add inline inspection, there’s no need to “start from scratch.”
Third, recipe storage and expansion. Equipment can store process parameters for up to 20 different products, with one-touch loading for changeover. When new products are added in the future, only new recipes are needed – no hardware replacement.
Fourth, reserved data interfaces. Equipment comes standard with OPC UA or SQL interfaces, supporting MES integration. When the customer’s factory undergoes digital upgrading, the equipment doesn’t need to be replaced.
4. The Practical Value of Modular Design for Overseas Buyers
Value 1: Lower initial investment risk. Customers don’t need to buy the highest configuration “all at once.” They can start with a basic configuration and gradually upgrade as the order mix changes.
Value 2: Extended equipment lifecycle. Modular-designed equipment can adapt to new products and processes through module upgrades, rather than being “scrapped when the product changes.”
Value 3: Reduced production stoppage for retrofits. Modular upgrades can be completed in a short time without long production stoppages. If all equipment on an optical fiber cable production line is modular-designed, the impact of upgrades on production can be minimized.
Value 4: Lower spare parts inventory pressure. Modular design means different machines can share modules. The entire fiber optic cable making machine series uses unified electrical and communication modules, reducing the variety of spare parts customers need to stock and simplifying management.
5. How Can Overseas Buyers Assess Modular Capability When Selecting Equipment?
Question 1: What expansion options does the equipment support? Can pay-off stands be added? Can inline inspection be added? Can the control system be upgraded?
Question 2: Are the electrical interfaces standard? If sensors or communication modules are added later, will the entire control cabinet need to be replaced?
Question 3: What PLC platform is used? Does it support data acquisition and MES integration? Are expansion interfaces reserved?
Question 4: Are there customer upgrade case studies? From how many tubes to how many tubes? From what product to what product?
📩 Get a Modular Equipment Configuration Proposal
If you are procuring a fiber optic cable production line for an overseas project, or want to learn about the modular design and future expansion capability of the equipment, feel free to contact the Hongkai technical team.
Just tell us three things:
-
What type of cable are you making now? What products might you expand to in the future?
-
Where will the factory be built? (This affects voltage system and certification requirements)
-
Approximately what capacity? (How many kilometers per month or per year)
We will provide a preliminary equipment configuration proposal, modular expansion recommendations, and a quotation within 5 working days.
